Turntable Details
Drive
Idler
Motor
AC
Wow & Flutter %
0.2
Rumble [dB]
Speed
16, 33, 45, 78
Dimensions [mm]
Platter Material
Platter Diameter [mm]
Total Weight [kg]
Tonearm
Year Built
J-shaped
Platter Weight [kg]
3.60
Plinth Material
Price
Additional information
The Goldring GL70 is a precision-engineered idler-drive turntable designed for high-quality audio reproduction. Here’s a detailed technical description:
Drive System: Idler drive, providing robust torque and stability.
Motor:4-pole constant velocity motor that ensures consistent speed.
Speed Control:Continuously variable speed control allows adjustment from above 80 RPM to below 30 RPM, with preset click-in positions for standard speeds of 78, 45, 33.3, and 16 RPM.
Platter:Die-cast from zinc and copper alloy, weighing approximately 8 lbs (3.6 kg).
The platter is dynamically balanced to minimize resonance.
Spindle:The center spindle is made of ground lapped steel and runs in a sintered bronze bush with a special thrust pad.
Wow and Flutter:Maximum wow and flutter is less than 0.2%, indicating excellent speed stability.
Rumble and Hum:Negligible levels of rumble and hum for quiet playback.
Pickup Arm:Fitted with the L70 pickup arm, which features a detachable plug-in shell and a built-in lowering device for the stylus.
Automatic Disengagement:The idler wheel automatically disengages when the arm is lifted.
Dimensions and Weight:
Specific dimensions are not provided in the search results, but the turntable is designed to fit standard audio setups.
Performance:
The GL70 is well-regarded for its sound quality, offering clear audio reproduction suitable for both monaural and stereophonic recordings. Its unique vertical drive system enhances its versatility in speed adjustment.
