Turntable Details
Drive
Direct
Motor
DC
Wow & Flutter %
0.03
Rumble [dB]
-60
Speed
33, 45
Dimensions [mm]
Platter Material
Platter Diameter [mm]
308.0
Total Weight [kg]
Tonearm
Year Built
5.50
S-shaped
1977
Platter Weight [kg]
Plinth Material
Price
Additional information
The Hitachi HT-350 is a direct-drive turntable that was produced in the late 1970s, known for its solid construction and reliable performance. Below is a detailed technical description of the HT-350.
Technical Specifications
Type: 2-speed direct drive turntable
Motor: DC servo motor
Speeds: 33 1/3 RPM and 45 RPM
Platter: 308mm aluminum alloy die-cast
Wow and Flutter: 0.03% (WRMS)
Signal-to-Noise Ratio: 60 dB
Tonearm Type: Static balance type
Effective Tonearm Length: 220mm
Overhang: 15mm
Dimensions: 454 x 366 x 137 mm (WxHxD)
Weight: Approximately 5.5 kg
Power Consumption: 4 Watts
Features
Automatic Mechanism: The turntable features a convenient automatic mechanism for ease of use.
Speed Adjustment: Allows for fine tuning of playback speed.
Oil-Damped Arm Lifter: Ensures smooth operation when lowering and raising the tonearm.
