Turntable Details
Drive
Belt
Motor
DC
Wow & Flutter %
0.25
Rumble [dB]
-50
Speed
33, 45
Dimensions [mm]
Platter Material
Platter Diameter [mm]
320.0
Total Weight [kg]
Tonearm
Year Built
10.15
S-shaped
Platter Weight [kg]
0.68
Plinth Material
Price
Additional information
Drive Type: Belt drive with a DC motor.
Speeds: Supports two speeds: 33 1/3 RPM and 45 RPM.
Speed Transition: Quick change from 33 RPM to 45 RPM in less than 1 second, and from 45 RPM to 33 RPM in less than 5 seconds.
Pitch Control: Adjustable pitch range of ±10% via slider.
Tone Arm: S-shaped with Cardan's suspension, featuring:
Tone arm length: 234 mm.
Overhang: 16 mm.
Adjustable stylus pressure: 0-4 g.
Anti-skating range: 0-7 g.Platter: Outer diameter of 320 mm, weighing 682 g.
Start Time: Less than 1 second.
Stop Time: Less than 1 second.
Wow and Flutter: Less than 0.25% WRMS.
Rumble: 50 dB DIN B.
Initial Torque: Greater than 650 g/cm.
Power Supply: 230 V AC, 50 Hz or 115 V, 60 Hz.
Power Consumption: 8 W.
Maximum Starting Current: 260 mA.
Output Connectors: RCA and 6.3 mm jack.
Dimensions: Width: 450 mm, Depth: 352 mm, Height: 148 mm.
Weight: Approximately 10 kg.
Additional Features
Manual Operation: Requires manual lifting of the tone arm to start and stop playback.
Strobe Lamp: For precise speed adjustment.
Target Lamp: For improved visibility.
Remote Start: Possible via a 6.3 mm connection on the rear panel.
Shock-Absorbing Feet: Reduces vibration.
Delivery Includes: Removable dust cover and a high-quality pick-up system qualified for back-cueing.
