Turntable Details
Drive
Direct
Motor
DC
Wow & Flutter %
0.2
Rumble [dB]
-50
Speed
33, 45
Dimensions [mm]
Platter Material
Platter Diameter [mm]
332
Total Weight [kg]
Tonearm
Year Built
11.3
S-shaped
Platter Weight [kg]
1.4
Plinth Material
Price
Additional information
Drive Type: Quartz-controlled direct drive with a brushless DC motor, providing high torque for stable operation.
Speeds: Supports three speeds: 33 1/3 RPM, 45 RPM, and 78 RPM, with both forward and reverse rotation capabilities.
Pitch Control: Offers pitch adjustments of ±10%, ±20%, and ±50%, making it suitable for DJ applications.
Tone Arm: S-shaped with Cardan's suspension, featuring an adjustable height of 8-10.5 mm and overhang of 15 mm (some sources list 20 mm).
Stylus Pressure: Adjustable from 0-4 g.
Anti-Skating Range: 0-7 g.
Platter: Made of metal, with a diameter of 332 mm and a weight of 1,400 g.
Start/Stop System: Adjustable start and stop times ranging from 0.2 to 6 seconds.
LED Illumination: Includes a plug-in LED target lamp for improved visibility.
Output: Switchable phono/line output via RCA connectors.
Power Supply: 230 V AC, 50 Hz, with a power consumption of 15 W.
Technical Specifications
Frequency Range: 20 Hz to 20 kHz.
Wow and Flutter: Less than 0.20% WRMS.
Rumble: 60 dB DIN B (some sources list 50 dB).
Dimensions: Width: 45 cm, Depth: 35.3 cm, Height: 15.6 cm.
Weight: Approximately 11.3 kg.
Initial Torque: Greater than 2.1 kg/cm.
Additional Features
Quartz-Controlled Pitch Lock: Ensures precise speed control.
Quick Start: Allows for rapid start-up.
Shock-Absorbing Feet: Reduces vibration and resonance.
Recessed Connections: Facilitates easy case mounting.
Delivery Includes: Slipmat, RCA cable, and optionally a dust cover and pickup system.
